301.474.150
360° Rotating Clamp with Rotating Forks
Residual Capacity Calculation

Rotating Clamp with Rotating Forks, suitable for handling goods on pallets or by tightening and rotating the load. The clamping force, which can be set through a hydraulic valve, allows a safe movement of the load. A pressure relief valve, a non-return valve and a regenerative valve are supplied as standard on each model. The rotation of the forks can be operated manually or, on request, by cylinders activated from a hydraulic function of the forklift. Minimum and maximum openings can be adapted to different needs, as the forks dimensions and length. Side Shifting Valve and Semi-Integral Sideshift, are also available on request.
